Vantage® IP Interlocking Plank System
Vantage® IP is an innovative, CWCT tested, secret-fix interlocking plank system. Drained and back ventilated, this cladding system is equally suitable for external walls, parapets and soffit applications. Additionally, the interlocking design allows for hidden fixings to improve aesthetic.
GALLERY
SYSTEM FEATURES
- Horizontal or vertical applications
- Euro class A1, A2, s1, d0 options available
- Tested in accordance with CWCT Standard for Systemised Building Envelopes
- Lightweight and flexible
- Ladyrinth joints, 6mm – 20mm joint gap both horizontal and vertical
- Large range of panel sizes and finishes available
- Cladding zone range 100mm – 370mm
- Plank depth 35mm deep as standard
- Top-down installation
- Easy installation
SEND US A MESSAGE
STYLE AND SIMPLICITY
Our innovative secret fix rainscreen system offers visually stunning results using panels of up to 4000mm x 600mm depending on which material is chosen from the comprehensive range on offer to our clients.
VANTAGE IP FAQS
Our Vantage IP® system is a cost-effective solution which is ideal for soffits, balconies and vertical rainscreen applications.
Due the intricate hairclip bend, we would only recommend this system on anodised and power coated 3mil aluminium.
This is subject to the expanse of metal between bends and static calculations.
